550 Series Single Bolt Pipe Clamp

550-SSBPC

Globe Pipe Hanger Products

Recommended For The Support And Stabilizing Of Vertical Pipe Runs.
(click image to enlarge)
Quick Overview

  • Size Range : 1/2" Through 30" Pipe Sizes.
  • Material : Carbon Steel
  • Finish : Black.
  • Ordering : Specify Finish; Model Number And Pipe Size.
  • Function : Recommended For The Support And Stabilizing Of Vertical Pipe Runs. Overall Length Is Less Than A Riser Clamp.
Interested in this item or want more information?
Monday - Friday, 6:30 am to 4:30 pm
Phone: 412-681-6673
Email: orders@constructiontoolservice.com

Can't find what you want? Give us a call and we can help you find it.
Details


ItemPipe SizeBolt Size Material ThicknessMaterial SizeMax. Recommended Load (At 650°F)Max. Recommended Load (At 750°F)
550 - 104 1/2 inches 3/8 inches 11 gauge 1 inches 500 lbs 445 lbs
550 - 106 3/4 inches 3/8 inches 11 gauge 1 inches 500 lbs 445 lbs
550 - 110 1 inches 3/8 inches 11 gauge 1 inches 500 lbs 445 lbs
550 - 112 1 1/4 inches 3/8 inches 11 gauge 1 inches 500 lbs 445 lbs
550 - 114 1 1/2 inches 3/8 inches 11 gauge 1 inches 800 lbs 715 lbs
550 - 120 2 inches 1/2 inches 3 gauge 1 inches 1040 lbs 930 lbs
550 - 124 2 1/2 inches 1/2 inches 3 gauge 1 inches 1040 lbs 930 lbs
550 - 130 3 inches 1/2 inches 3 gauge 1 inches 1040 lbs 930 lbs
550 - 134 3 1/2 inches 1/2 inches 3 gauge 1 inches 1040 lbs 930 lbs
550 - 140 4 inches 5/8 inches 3 gauge 1 1/4 inches 1040 lbs 930 lbs
550 - 150 5 inches 5/8 inches 3 gauge 1 1/4 inches 1040 lbs 930 lbs
550 - 160 6 inches 3/4 inches 3/8 inches 1 1/2 inches 1615 lbs 1440 lbs
550 - 180 8 inches 3/4 inches 3/8 inches 1 1/2 inches 1615 lbs 1440 lbs
550 - 1100 10 inches 7/8 inches 1/2 inches 2 inches 2490 lbs 2220 lbs
550 - 1120 12 inches 7/8 inches 1/2 inches 2 inches 2490 lbs 2220 lbs
550 - 1140 14 inches 7/8 inches 1/2 inches 2 inches 2490 lbs 2220 lbs
550 - 1160 16 inches 7/8 inches 1/2 inches 2 1/2 inches 2490 lbs 2220 lbs
550 - 1180 18 inches 1 inches 5/8 inches 2 1/2 inches 3060 lbs 2730 lbs
550 - 1200 20 inches 1 1/8 inches 5/8 inches 2 1/2 inches 3060 lbs 2730 lbs
550 - 1240 24 inches 1 1/4 inches 5/8 inches 3 inches 3060 lbs 2730 lbs
550 - 1300 30 inches 1 1/2 inches 3/4 inches 4 inches 4000 lbs 3520 lbs
Additional Information
Manufacturer: Globe Pipe Hanger Products
For More Information on the 550 Series Single Bolt Pipe Clamp, [Click Here] to Link to Manufacturer Web Site
