SnapToggle Heavy Duty Toggle Bolts



(click image to enlarge)
Quick Overview
    • Smallest drill hole for each bolt size — 1/4" wing toggle needs 50% larger hole
    • High strength — holds up to 2x the load of an old-fashioned wing toggle of same bolt size
    • Reusable in same hole — remove the bolt without losing the anchor
    • One-person installation — like having an extra pair of hands behind the wall
    • Insulation pushed aside by metal channel
    • Does NOT destroy wall or ceiling — plastic cap & metal channel centers bolt & prevents abrasion
Interested in this item or want more information?
Monday - Friday, 6:30 am to 4:30 pm
Phone: 412-681-6673
Email: bconnelly@constructiontoolservice.com

Can't find what you want? Give us a call and we can help you find it.

Most major manufacturers of hand rails and of TV mounts either package the SNAPTOGGLE anchors with their products or specify them for installing their products.

Tensile Test Results (Ultimate results in pounds*)
Anchor/Bolt Thread1/2" Drywall5/8" DrywallConcrete1/2" Steel Plate
BA 3/16"-24238356802**918
BB 1/4"-202653561080**1283
BE 5/16"-1827048014001680
BC 3/8"-162755761745**1692**
BD 1/2"-1327557620382605**
BM6 M6 [Ø6mm]229-733870

**New, improved holding values

Shear Test Results (Ultimate results in pounds*)
Anchor/Bolt Thread1/2" Drywall5/8" Drywall
BA 3/16"-24247298
BB 1/4"-20241324
BC 3/8"-16292406

*Industry safety standards recommend 1/4 of ultimate load.

NOTE: A dash (-) in the chart above indicates no test result is currently available.
BA 3/16"-24 & BB 1/4"-20 require a 1/2" dia. drill hole.
BE 5/16"-18, BC 3/8"-16 & BD 1/2"-13 require a 3/4" dia. drill hole.
BM6 (M6) requires a 13mm dia. drill hole.

SNAPTOGGLE anchors get their name from their speed and ease of use—they work in a SNAP!

The third generation of our patented SNAPTOGGLE anchors has these improvements:
  • new longer and stronger plastic straps that now work in base materials 3/8" to 3 5/8" thick and will not break prematurely like other plastic straps
  • straps that snap off flush with the wall every time, assuring precise alignment
  • a new plating that is 7x more corrosion-resistant than B633-85 Type III/Sc 1 government spec zinc plating
    [Also available in RoHS-compliant plating and in stainless steel]
Additional Information
Manufacturer: Toggler
For More Information on the SnapToggle Heavy Duty Toggle Bolts, [Click Here] to Link to Manufacturer Web Site
